과제명 | 선박의 조종-운동 통합 성능 해석을 위한 기초연구 |
---|---|
주관연구기관 |
선박해양플랜트연구소 Korea Research Institute of Ships &OCEAN Engineering |
연구책임자 | 김연규 |
참여연구자 | 여동진, 윤근항, 이경중, 김동진, 김광수, 남보우, 황승현, 김유철, 김윤식, 김진, 조석규 ... |
보고서유형 | 최종보고서 |
발행국가 | 대한민국 |
언어 | 한국어 |
발행년월 | 2016-12 |
과제시작년도 | 2016 |
주관부처 | 해양수산부 Ministry of Oceans and Fisheries |
등록번호 | TRKO201800014318 |
과제고유번호 | 1525006242 |
사업명 | 선박해양플랜트연구소연구운영비지원 |
DB 구축일자 | 2018-06-02 |
키워드 | 조종성능.운동성능.조종-운동 통합 성능.모형시험.조종-운동 통합 시뮬레이션.Maneuverability.Seakeeping ability.Integrated ability of maneuvering and seakeeping.Model test.Integrated simulation of maneuvering and seakeeping. |
DOI | https://doi.org/10.23000/TRKO201800014318 |
O 연구개발목표
- 선박의 조종-운동 통합 성능 해석을 위한 기초기술 개발
O 연구개발내용
- 선박의 조종성능 추정 정도 향상 방안 검토
- 선박의 운동성능 추정 정도 향상 방안 검토
- 선박의 조종...
O 연구개발목표
- 선박의 조종-운동 통합 성능 해석을 위한 기초기술 개발
O 연구개발내용
- 선박의 조종성능 추정 정도 향상 방안 검토
- 선박의 운동성능 추정 정도 향상 방안 검토
- 선박의 조종-운동 통합 성능 추정기술 기초연구
- CFD기법과 HPC를 활용한 선박의 동적 운동 수치해석 기초연구
O 활용계획 및 기대효과
- 선박의 조종성능 및 운동성능 추정 정도 향상 방안 검토
- 파도 중 운항하는 선박의 성능추정을 위한 기초기술 확보
- 조종-운동 통합 성능 검증용 시험 방안 확보
- 모형선의 운항성능 추정을 위한 기초 기술로 활용
- IMO 및 ITTC의 조종-운동 통합 성능 추정기술 관련 기술적 대응
( 출처 : 보고서 초록 5p )
The technology about the analysis of ship’s integrated ability of maneuvering and seakeeping are interested as IMO and ITTC has bi...
The technology about the analysis of ship’s integrated ability of maneuvering and seakeeping are interested as IMO and ITTC has bigger interests in that technology.
And the technology is an important role of IMO’s activity about the minimum propulsion power of a ship in the adverse weather condition. The most reliable method for the analysis of ship’s integrated ability of maneuvering and seakeeping is free running model test in waves. But this method is very difficult, expensive and time consuming. Therefore the simulation technology for the analysis and the model tests for the verification of simulation are studied much. To simulate the maneuvering motion in waves the integration of maneuvering and seakeeping motion in the time domain is necessary.
The purpose of this project is a fundamental research for the analysis of ship’s integrated ability of maneuvering and seakeeping. To achieve the goal of this project the investigation of improving method of the prediction accuracy of ship’s maneuverability and seakeeping ability, fundamental research of the prediction of ship’s integrated ability of maneuvering and seakeeping have done. And the fundamental research of numerical analysis technology of ship’s dynamic motion by CFD and HPC has also done.
The results of this research are the obtains of the development method of integrated simulation program of ship’s maneuvering and seakeeping, the development method of integrated model test and fundamental research of CFD technology of ship’s maneuvering and seakeeping.
The expected contributions of this research are the utilization to the fundamental technology for the prediction of navigation performance of a model ship and the technical action to IMO and ITTC about the prediction technology of ship’s integrated ability of maneuvering and seakeeping
( 출처 : SUMMARY 및 KEYWORDS 8p )
참여 연구원 | 여동진, 윤근항, 이경중, 김동진, 김광수, 남보우, 황승현, 김유철, 김윤식, 김진, 조석규, 서민국, 김경환, 유윤규, 이영연, 안해성, 김명수, 김철희, 홍사영, 김진하, 임태구, 이창용, 권기진, 김영식, 최성권, 유선모, 김명석, 황성철, 최영명, 김남우, 하윤진, 정현우, 원영욱, 조혜정, |
---|
선박의 조종-운동 통합 성능 해석을 위한 기초연구
주관연구기관 : 선박해양플랜트연구소
Korea Research Institute of Ships &OCEAN Engineering
책임연구자 :
김연규
발행년월 : 2016-12
